AEA Challenger Bullpup Tuning Regulator by Huma-Air
Huma-Air High Power Pressure Regulator for tuning your AEA Challenger Bullpup airrifle to the best performance.
Huma-Air Tuning Regulator For AEA Challenger Bullpup
For the AEA Challenger Bullpup we have a high volume pressure regulator available suitable up to caliber .30
This regulator is vented to the atmosphere without any modification to your pressure tube. So no drilling in the tube and also no creeping up in power during time.
The benefits of the AEA Challenger Bullpup tuning regulator are:
- Higher accuracy of your rifle due to the elimination of the pelletspeed fluctuations
- A constant pellet speed over the full working pressure range.
- Maxiumum use of the air volume due to our ultra compact build.
- It will give you a better shotcount and a full flat shotstring immediately.
- Adding a regulator to your airrifle will probably give you the biggest benefit in the tuning process.
- Often the rifle will make less noise due to better balance in air usage
When you order your Huma-Air, AEA Challenger Bullpup tuning regulator you will receive:
- Your regulator preset to your own wishes;
- A pressure scale in Bar’s on the regulator, for fine-tuning or re-adjustment;
- We will include a “Huma-Air regulated” breech sticker;
- Fitting instructions as pdf download.
Huma-Air Quality Control
Huma Air regulators are CNC produced out of high grade aircraft aluminum and bronze. To guarantee a perfect product, every regulator is individually assembled, tested in a computerized simulation program and adjusted to the requested pressure.
We only use high-end materials and our belleville springs are designed for critical applications to achieve the highest repeat accuracy. This gives our regulators a repeat cycle less than 1% difference.
Huma Air provides a 2-year warranty on their regulatiors. Excluded from warranty are shipping costs and parts that are subject to normal wear and tear such as o-rings and valve discs.
Pressure settings of the Huma-Air, AEA Challenger Bullpup tuning regulator
Your AEA Challenger Bullpup Tuning Regulator comes preset on the most common pressure setting.
It is equipped with a clear pressure scale label, so you can very easy re-adjust, or fine tune the pressure setting without the need of a regulator pressure tester.
The output pressure range is stepless adjustable from 90-170 bar.
Specifications
Brand |
---|
Shipping and Payment
We ship these parts well packed for safe and undamaged arrival in the country of destination with tracked priority shipping (unless this is specifically stated otherwise in the product text). As the purchasing party you are responsible for checking that this product is legal according to your local laws and regulations. We ship on your behalf and therefore Huma Air can not be held responsible for any legal issues in the country of the recipient.
You can pay safely and secure online by means of all major payment providers, like paypal and credit cards companies.
Eric s (verified owner) –
Was having problems with the original regulator on my Aea challenger regulated bullpup. Bought this and removed the original reg, but kept the original plenum installed and piggy backed the huma plenum and reg on top. Now I get 24 shots at 55 fpe with a extreme spread of 10fps. Reg set to 150 bar. Super happy. I have huma regs on all my airguns.
Tom (verified owner) –
Heb deze reg. geplaatst in mijn AEA Challenger Bullpub 25cal.. en jaag de Zan’s 37grn met 948Fps over het veld..
20 schoten vanaf 300bar ,eind druk 165Bar (volgens de AEA mano) met een reg. setting van 170Bar.. verbluffende resultaten..
100mtr grouping onder een inch.. met 15kmph zijwind.. zelfs doelen op 200mtr van 10cm zijn haalbaar..
Top regulator ,
Thanks Huma!!
David Hagerman (verified owner) –
This regulator fit the AEA Challenger 30 cal perfectly. The regulator was eazy to adjust and performed flawlessly. This regulator will fit both the AEA Challenger 30 and 35 caliber air rifles.
David Hagerman (verified owner) –
This regulator guality is excellent fit was perfect and regulates pressure with no more than 5 psi variance.
Matt Tripp (verified owner) –
Hello, received the regulator for my AEA Challenger 35 cal
Installs easily, set to 160 bar / 2320 psi
Refilled to 250 bar
Shot this string
849
842
842
842
842
837
837
Spread 12
SD 3.7
Energy 127 ft lbs
Start pressure 250 finish pressure 150 bar
Shoots really nice, almost soft compared to the earth shaking violent report before the reg. Super accurate, hole in hole at 30 yards with JSB 35 cal 81.02gn!
Very very pleased with this regulator!
Thanks Huma!
Matt Tripp aka Prospector Tripp YouTube
Sylvanicus (verified owner) –
This regulator set at 170 bar puts 53gr bullets from a .25ACP bullet mold into the same hole at 20 yards. So well in fact that I thought I missed 3 times in a row. Nope. Same hole. Still touching at 40 yards. Even when my 10 year old shoots it. I haven’t tried or tuned the regulator for pellets, but it sure is a great shooter with my 53 gr cast bullets. Highly recommended. Very easy to install too. And much quieter.
Art Burhoe (verified owner) –
I contacted Huma Regulator they were very helpful, I asked them to set my Regulator to 190bar. My regulator arrived no instructions and web site link did not work. I managed to install the regulator. I was trying to get 60- 65fpe from my .22 AEA Challenger Bullpup. My figures showed 190bar would be close to what I needed. My .22 is at 55fpe with ZAN 28gr slugs . I am getting 26 regulated shots and exceptional accuracy. I would highly recommend this regulator. If it had a larger plenum I would install one in my .30 /32″ Challenger.
Steve (verified owner) –
I’ve seen many airguns with the Huma regulators so I was confident I was getting the best, when I installed this one in my Aea challenger bullpup I was amazed. Shot count went up and accuracy is great, I’ve been telling everyone about it so I can help all the rest of the people like me that bought a unregulated gun and was disappointed. Thanks Huma.
Scott (verified owner) –
Best upgrade u can do for this gun Huma regulator in 30 cal AeA challenger bull pup it made this gun much more accurate and uses much less air must use much lighter hammer spring ace hardware 5/8 inch shorter spring then shorten spring 1 coil at a time until chronograph peaks
Kenney (verified owner) –
I have purchased 3 of these regulators and they work as advertised. Have them in 2 .25 calibers. They shoot much tighter groups and the gun is noticeably quieter. Recommend getting the regulator tester to dial in the regulator before installing.
Mark M (verified owner) –
You may need to cock the rifle before filling it up or you could experience a valve leak!
Besides this hiccup that confused me for a few hours, I can honestly say this is one of the best regulators I’ve ever seen! My shot variance is typically 5-6 psi over a 12 shot string at 165 bar. I’m shooting nielsen 54.5 gain slugs at 910 average fps for a perfect 100 ft lbs in the challenger bullpup .30. I’m hitting squirrels at 150 yards with just a few mil hold over and it’s consistent. Took a gun that was raw power and made it a tight grouping monster. Easy 1/2 inch Groups at 50 and just over an inch at 100!
Charlie Owen (verified owner) –
This is my second Huma regulator and both operate flawlessly. Huma has been great to work with. Shipping to my house in the state of Kansas in the USA was less than 4 days. I was impressed!
This regulator is installed in an AEA Challenger 32 inch barrel .30 cal. I set regulator to 170 bar. Aired up to 4300 psi I managed 15 shots of 61.5 grain NSA slugs at 1030-1035 fps before it fell off the regulator Very consistent.
Doug Howard (verified owner) –
Great regulator once you get it installed. At 170 bar reg pressure I get 915fps avg with 44.75 JSB’s and the accuracy is awesome along with consistent pellet speed. I love my reg in my .30 cal Challenger Standard Long Stock. I would recommend this to anybody owning the Challenger series air rifle.
Llaniteco (verified owner) –
I’m very impressed with this regulator. Installed it in less than 15 minutes. I have a video on my channel on YouTube installing the regulator. I set mine at 168 bars (2400 psi) now I get consistent shoots with slugs going at 905 fps. That’s 119 foot pounds. The slugs are 65.5 grains.
Estoy muy impresionado con el regulador. Lo instale en menos de 15 minutos. Tengo un video en mi canal de YouTube en el cual muestro como instalarlo y el desempeño. Puse el regulador a 168 bars o 2400 psi. Ahora mi rifle challenger bullpup cal 30 dispara slugs de 65.5 granos a 905 FPS. Me da una fuerza de 119 libras de fuerza.
Kenney (USA) (verified owner) –
Purchased 2 of the AEA challenger Bullpup tuning regulators for my .25 and .30 calibers. First off I ordered them on a Monday and got them on Thursday the same week. Unbelievable that they can get this half way around the world in 3 days!!! Way to go Huma!!
After taking the time and chronograph to set these up the results were dramatic. The guns are noticeably more quiet and very accurate. Add a moderator to it and nothing more than a wisp of air can be heard with even tighter groups. If you are serious about your pcp a tuning regulator is a must.
